●Can Extend Length 0.7M, Desirable For Different H/P Tractor And
Suitable For Complex Road Environment.
●Four-Wheel+ Hydraulic Control System + Solenoid Valve+Oil Pipe + Tripod
●Providing Extra Long Width Customized Range to 4M
●Manganese Steel Blade
Place of Origin:
Hebei, China (Mainland)
Brand Name:
BJTB
Blade Attaching System: Four-wheeled+ Hydraulic system + Oil pipe + Tripod
Length: 2-4M Can be customized by order
Height:3.2M
In order to have better result of leveling land, different horse power tractor should match different length of box blade. We recommend the below tractor H/P with matching box blade length for your to consult.
50--80Hp should match 2.0--2.5M box blade
80--90Hp should match 2.5M box blade
120Hp should match 3.0M box blade
140Hp should match 3.2--3.5M box blade
175Hp should match 3.5--3.8M box blade
The adjustable width box blade can extend 0.7M length.
For example:
a) Width before stretch out 2.5M, after can reach 3.2M
b) Width before stretch out 3M, after can reach 3.7M
*Important: Please be noticed that all of our box blade can be only carried by 4WD tractor,
There should be always aware of maintenance and don’t stretch out and draw back the blade very frequently, this behavior will shorten working life of the box blade. Proper operation can prolong its working life.
